46692902 | Universal 6380 Radial Insertion Head Drive Assembly (Spindle Ball Screw Assembly)
46692902 Universal 6380 Radial Insertion Head Drive Mechanism, Ball Screw Spindle Assembly for AI Radial Insert Machine
P/N:46692902, Complete drive mechanism for Universal 6380 radial insertion head, integrated ball screw & spline shaft assembly, original specification replacement spare part for AI THT insertion machine.
Share to:
Applicable Models: Universal 6380 Radial Component AI Automatic Insertion Machine (6380A/6380B/6380H universal component), a core integrated ball screw + spline spindle assembly for the insertion head.
🔧 Product Structure and Function
1. Integrated Component: A complete drive mechanism consisting of a ball screw, spline spindle, ball nut, and spline nut; not a single screw.
2. Function: Controls the vertical Z-axis insertion movement of the radial insertion head, completing the insertion of radial resistors, diodes, and other components into the PCB board, along with bending and trimming the leads.
During handling and assembly, it is strictly forbidden to push the spline nut/ball nut to either end of the screw to dislodge it; once the nut detaches from the screw, the entire assembly is rendered unusable and cannot be restored; replacement with a new part is required.
