ITW Vitronics Soltec L600467
L600467 is an original ITW Vitronics Soltec flux vessel/tank, compatible with their selective wave soldering spray/jet flux systems. It is a standard pressure-type feed reservoir.
Official Name: Flux Tank Assembly (Main), L600467
Applicable Models: mySelective 6748, 6747, ZEVAm+, ZEiA Series Selective Welding Equipment
Positioning: Main working tank in a dual-tank system (with a supplementary tank), featuring a liquid level monitoring interface and a pressure/liquid outlet interface
Share to:
Key Parameters (Original Standard)
Capacity: 1.0L (1000ml), standard working volume
Material: Food-grade PP (polypropylene), resistant to flux (no-wash/lead-free/water-based) corrosion and impermeable
Interface Configuration:
Top: Pressure inlet (4mm/6mm quick-connect), liquid level sensor mounting hole (inductive/capacitive), exhaust/pressure relief port
Bottom/Side: Flux outlet (Φ6mm/Φ8mm), sealing and locking structure
Functions: Adapted to constant pressure feeding (300–400mbar), low liquid level alarm, automatic replenishment, with anti-sedimentation/ Bubble Design
Dimensions (Reference): Approx. Φ100mm × Height 180mm (including interface)
Structure and Installation Points
Dual Tank System: L600467 is the main tank, and the auxiliary tank commonly uses part number L600468. Automatic switching and replenishment during production without stopping the machine.
Level Compatibility: Matches original 38515 inductive level sensor (Baumer IFRM series), low level triggers alarm/replenishment.
Sealing: Standard fluororubber O-ring, flux-resistant and leak-proof; recommended replacement every 3–6 months.
Filtration: Integrated 180μm filter element inside the tank/outlet to prevent nozzle clogging.
Procurement and Alternatives
1. Original Manufacturer Procurement (ITW EAE Channel)
Channel: ITW EAE China Distributor, Original Parts Center
Note: Equipment serial number must be verified to ensure model compatibility.
Common Faults and Maintenance
Leakage: Replace O-ring, check quick-connect fittings / Threaded Seal
Inaccurate Liquid Level: Clean the sensor probe, calibrate the trigger threshold, and remove air bubbles from the tank.
Unstable Feeding: Check the inlet pressure, ensure proper venting, check for filter blockage, and inspect for sediment in the tank.
Replacement Cycle: It is recommended to replace the entire tank every 6–12 months to prevent aging, cracking, and flux contamination.
Quick Confirmation Checklist
You need to check:
Equipment Model (mySelective 6748 / ZEVAm+)
Is it the main tank (L600467) or the auxiliary tank (L600468)?
Interface Type (Quick Connect / Threaded, Pipe Diameter), and whether it includes a weighing module.
