ASM SMT Machine X Series Feeders

ASM SMT 2x8MM Feeder wthout Sensor 00141479 is a key component in the feeding system of ASM SMT The following is acomprehensive introduction to it:
Basic Information
Model 00141479, belongs to the 2X8MM Feeder series of ASM SMT, suitable for processing material tapes wth a width of 8MM, and hastwo feeding channels, which can supply two different materials at the same time to improve production efficiency.
Type: Feeder without sensor. Compared with the feeder with sensor, i does not have the function of automaticaly detecting the remainingamount of matenials, component position, etc., and requires operators to monitor and manage in other ways.
Structural Design
Reeling mechanism used to install and fix the reel shaped materaltape, and drive the materal tape to be gradualy released through therotating shaft.
Transmission system usualy composed of a gear set and a stepper motor, which can accurately control the feeding step of the materal
tape to ensure that the components are accurately delivered to the pick-up positionTape pressing device: fix the tape in the feed trough to prevent the tape from shifting or shaking during the conveying process. At thesame time, there is a separation plate at the front end of the tape to separate the upper tape from the tape base so that the patch headcan pick up the components smoothly.
Tape take-up wheel: responsible for collecting the peeled upper tape to keep the tape neat and orderly
